New COSEN C-800NC | Horizontal Dual Column Band Saws

Description

Band Saw Machine

800mm Automatic horizontal dual column type band saw incorporates a 10hp powerful blade motor, 67mm (2.6") wide blade, independent control panel, and heavy-duty dual column design. These features create a very rigid, dynamically stable and productive machine. The heavy-duty dual columns always keep the blade parallel to the material creating equal force throughout the entire cutting cycle, thereby increasing the cutting efficiency and extending blade life.

Standard Features

• 7" HMI Touch Screen.
• Hydraulic dual column design.
• Gearbox design to accept high lateral pressure (no thermal distortion).
• Inverter blade drive system allows infinitely variable blade speeds.
• Carbide blade guides.
• Automatic hydraulic blade tensioning device.
• Integral coolant system.
• Ductile cast iron vise.
• Save-A-Blade feature.
• Precision feed pressure and feed rate dual valve system for optimal cutting performance.
• Split front vise jaws for a burr-free cut.
• Computer controlled multiple indexing up to 999" max length.
